SOMFY RTS Dry Contact Interface (Single Channel) (MPN #1810493)

The RTS dry-contact Interface can be used to communicate between home automation, commercial controls, or other third-party systems and SOMFY’s RTS products. Once a command is activated, an RTS signal is sent to the RTS product to set it in motion as desired.

◼︎ FEATURES

THE SOMFY RTS DRY CONTACT INTERFACE HOME AUTOMATION INTERFACE DEVICE FOR SOMFY’S PRODUCTS THAT ARE COMPATIBLE WITH RTS RF TECHNOLOGY. THE SOMFY DRY CONTACT INTERFACE OPERATES THE SIMILARLY TO THE TELIS 1 CONTROL EXCEPT THAT YOU CAN CONNECT RELAYS OR EXTERNAL BUTTONS TO THE WIRES TO CONTROL THE MOTOR. THE DRY CONTACT INTERFACE HAS A SINGLE RTS CHANNEL THAT AN UNLIMITED NUMBER OF SHADES CAN BE ASSIGNED TO BUT ALL SHADES ON THIS SINGLE CHANNEL WILL ALWAYS BE CONTROLLED AT THE SAME TIME. WHEN USED WITH THE SOMFY RTS MOTORS IT CONTROLS UP, DOWN, STOP AND CUSTOMER PREFERRED LOCATION COMMANDS. RTS TECHNOLOGY RF CONTROL DEVICES HAVE A 65 RANGE THROUGH 2 CONCRETE WALLS AND NEARLY A 100 CLEAR PATH RANGE. THIS DEVICE IS PACKAGED IN A WEATHERPROOF ENCLOSURE. NO EXTERNAL POWER SUPPLY IS REQUIRED. THE DRY CONTACT INTERFACE OPERATES ON AN INCLUDED LITHIUM COIN CELL BATTERY.

◼︎ CHARACTERISTICS

Applications: Awning, Exterior Solar Screens, Interior Window Coverings, Pergola, Rolling shutter
Radio Frequency: 433.420 MHz
Range in house: 65.62 ft
Range in open field: 65.62 ft
Approval: CE
Insulation class: Class II
Protection Index: IP 20
Color / Finish: White
Range: ANIMEO
Range details: PROTOCOLE INTERFACE
Product benefits:
Expand Integration
- Dry contact integration of RTS products into third-party home automation systems.
- Offers 1 channel of RTS control per interface.
- Battery-powered for convenient usage.
- Works with all RTS motors and receivers.
Type: Controls
Embedded Technologies: RTS
